Beskrivelse
Rated line pull: 1,361 kg (3,000 lb) single line
- Motor: 800 w / 1.0 hp 12V permanent magnet
- Gear train:3-stage planetary 138.5:1
- Clutch (freespooling):Sliding pin and ring gear
- Brake:Mechanical spring applied and permanent magnet motor dynamic brakes together
- Winch construction:Aluminum die cast housings and drum
- Drum size:55 x 75 mm (2.2” x 3”)
- Control:Handlebar rocker switch
- Rope type:Synthetic rope
- Rope size:4.8 mm x 15.2 m (3/16” x 50’)
- Mounting bolt pattern:76 x 124 mm (3” x 4.9”)
Standard Compliance:
– CE Machinery Directive 2006/42/EC
– CE EMC Directive 2014/30/EU
- Line Speed and Amp. Draw (1st layer of wire rope on the drum):
| Line Pull, kg / lb |
Line Speed, mpm / fpm |
Amp. Draw, A |
| 12V | ||
| No load | 5.7 / 18.7 | 25 |
| 227 / 500 | 4.8 / 15.7 | 50 |
| 454 / 1,000 | 4.0 / 13.1 | 80 |
| 680 / 1,500 | 3.5 / 11.5 | 110 |
| 907 / 2,000 | 3.0 / 9.8 | 140 |
| 1,134 / 2,500 | 2.5 / 8.2 | 180 |
| 1,361 / 3,000 | 2.0 / 6.6 | 230 |
- Line Pull and Rope Capacity:
| Layer of Rope | Pull by layer, kg / lb | Total Rope on the Drum, m / ft |
| 1st | 1,361 / 3,000 | 2.8 / 9.3 |
| 2nd | 1,173 / 2,585 | 6.1 / 20.1 |
| 3rd | 1,030 / 2,271 | 9.9 / 32.5 |
| 4th | 918 / 2,025 | 14.1 / 46.3 |
| 5th | 829 / 1,827 | 15.2 / 50 |
Winch weight (including rope) : 7.2 kg / 15.9 lb
