Come Up vinsj MadX 8.0S Extreme Racing

kr 24.024

  • 12V DC severe duty winch rated at 8,000 lb pulling meets or exceeds your expectations.
  • Heavy duty series wound motor equipped with thermal switch alters when motor over-heating.
  • 16 equally positioned pin holes with a stainless steel ergonomic T-handle make it possible to reposition in 22.5 degree Increments.
  • Water-proof remote control with thermometric LED indicator w/17 ft cord
  • A 12 strand construction synthetic rope coated to improve abrasion and has no water absorption.
  • Tough aluminum die cast housings withstand strength of 2.0 x rated load of winch
  • The U.S. Germany, U.K. France, etc patented mechanical cone brake outside the drum expedites heat dispersion and also makes the winch ideal for use with synthetic rope.

2 på lager

Varenummer: COM296065 Kategorier: , , , , Varemerke:

Beskrivelse

  • Part number: PN 296065 (12V ) 10″ Long Drum
  • Rated line pull: 3,630 kg / 8,000 lb single line
  • Motor: 5,250 w / 7.0 hp 12V series wound
  • Gear ratio: 3-stage planetary 67:1
  • Clutch (freespooling): Rotating ring gear
  • Brake (outside the drum): Automatic, full load CBS (Cone Brake Structure)
  • Winch construction: Aluminum die cast housings with steel drum
  • Drum size: 63.5 mm x 227L mm (2.5” x 8.9”L)
  • Control: Waterproof remote with thermometric indicator LED w/ 5 m (17′) cord
  • Rope type: Synthetic rope
  • Rope size: 10 mm x 30.5 m (3/8” x 100’)
  • Mounting bolt pattern: 254 mm x 114 mm (10” x 4.5”)
  • Finish : Matte black powder-coated
  • Winch weight (including rope) : 28 kg / 61.7 lb
  • Gross weight : 40.5 kg / 89.1 lb
  • Box dimension, (L x D x H) : 712 x 209 x 430 mm (28″ x 8.2″ x 16.9″)

Line Speed and Amp. Draw (1st layer of rope on the drum):

Line Pull,
kg / lb
Line Speed,
mpm / fpm
Amp, Draw,  A
12V
No load
25 / 82
45
907 / 2,000
10.8 / 35.4
125
1,814 / 4,000
8.5 / 27.9
249
2,722 / 6,000
4.1 / 13.5
378
3,630 / 8,000
1.0 / 3.3
500

Line Pull and Rope Capacity:

Layer of Rope
Pull by layer, kg / lb
Total Rope on the Drum, m / ft
1st
3,630 / 8,000
5.8 / 19.1
2nd
2,924 / 6,446
13.1 / 42.9
3rd
2,449 / 5,399
21.7 / 71.2
4th
2,106 / 4,643
30.5 / 100
